115 HORSEPOWER - ARCHIVE CAT 83778

> Mercury Marine [Updated: Nov. 15, 2017] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > ARCHIVE CAT 83778

MARINER
115 HORSEPOWER
115 (6 CYL.) . . . . . . . . . . . . . .  USA 4865178 THRU 5430526
115 (6 CYL.) . . . . . . . . . . . . . .  8057045 THRU 8062459

90-83778 © Mercury Marine 2003 02-01-2002

COWLING AND FRONT COVER

Diagram 84980-6



1
6497A2 COWL FRONT COVER ASSEMBLY (WITHOUT DECALS)

11
6498A3 WRAP AROUND COWL ASSEMBLY (WITHOUT DECALS)



MARINER DECALS

77550A78 DECAL SET UNITED STATES 5180698 AND BELOW

87133A79 DECAL SET UNITED STATES 5180699 AND UP AUSTRALIA 8057045 AND UP



FUEL TANK ASSEMBLY (6 GALLON)

Diagram 83778-66

1529A16 FUEL TANK ASSEMBLY, COMPLETE (6 GALLON)

1
1529 FUEL TANK (6 GALLON)

75881 DECAL, FUEL TANK



REMOTE CONTROL ASSEMBLY (ELECTRIC)

Diagram 83778-68

29 76703 DECAL, CONTROL HOUSING (MARINER) - NOT AS SHOWN

30 64043 DECAL, CONTROL HOUSING (MERCONTROL)



REMOTE CONTROL ASSEMBLY (ELECTRIC) (BOSCH)

Diagram 83778-72

14 77992 DECAL, REMOTE CONTROL COVER (NOT AS SHOWN)

Serial Number: 05181075 - Model: 7115629 - Version: ELPT
1979 MARINER 115 ELPT (6 CYL.)

40/50 H.P. - ARCHIVE CAT 809729

> Mercury Marine [Updated: May. 8, 2018] > Outboard > Force > 40 H.P. (1996-1997) > ARCHIVE CAT 809729
40/50 H.P. - ARCHIVE CAT 809729
90-809729

40/50 H.P.                             SERIAL NUMBER
40 H.P. (1996) . . . . . . . . . . . . E138600 THRU E202999
40 H.P. (1997) . . . . . . . . . . . . E203000 THRU E287999
50 H.P. (1996) . . . . . . . . . . . . E138600 THRU E202999
50 H.P. (1997) . . . . . . . . . . . . E203000 THRU E287999


COWL ASSEMBLY-TOP DIAGRAM 809729-4

819748A4 COWL ASSEMBLY-TOP (PAINTED) (WITHOUT DECALS)
819748T6 COWL ASSEMBLY-TOP (PAINTED)

819748A4, 819748T6
819748A4 819748T6


FORCE DECALS

820734A95 DECAL SET (FORCE-40 HP) (INCLUDES FRONT-REAR-PORTSTARBOARD)
820735A95 DECAL SET (FORCE-50 HP) (INCLUDES FRONT-REAR-PORTSTARBOARD)

1995 H040312RD, H040312RR, H040312RX, H040412RD
1996 H040312SD, H040312ST, H040412SD, H040412ST
1997 H040312TD, H040312TT, H040412TD, H040412TL, H040412TT

1995 H050312RD, H050312RR, H050312RX, H050412RD
1996 H050312SD, H050412SD, H050412ST
1997 H050312TD, H050412TD, H050412TT


NORTHWOOD DECALS

835012A96 DECAL SET (NORTHWOOD-40 HP) (INCLUDES FRONT-REARPORT-STARBOARD)

1996 H040312SD, H040312ST, H040412SD, H040412ST.
1997 H040312TD, H040312TT, H040412TD, H040412TL, H040412TT.
1998 H040312UD, H040312UT, H040412UD, H040412UL, H040412UT.
1999 H040312VD, H040312VT, H040412VD, H040412VL, H040412VT.

1996 H050312SD, H050412SD, H050412ST COWL.
1997 H050312TD, H050412TD, H050412TT COWL.
1998 H050312UD, H050412UD, H050412UE, H050412UT.
1999 H050312VD, H050412VD, H050412VT.



TRACKER DECALS

(INCLUDES FRONT-PORT & STARBOARD WRAPAROUND STYLE)
809858A96 DECAL SET (TRACKER-40 HP) (SER. # 0E138600 THRU 0E252999)
852950A97 DECAL SET (TRACKER-40 HP) (SER. # 0E253000 THRU 0E287999)
809859A96 DECAL SET (TRACKER-50 HP) (SER. # 0E138600 THRU 0E252999)
852951A97 DECAL SET (TRACKER-50 HP) (SER. # 0E253000 THRU 0E287999)

OTHER DECALS

COWL ASSEMBLY-BOTTOM - page 4-6
27 37-818029  DECAL-FUEL MIX

IGNITION AND ELECTRICAL COMPONENTS
5 FA609853  DECAL KIT-SHIFT TO NEUTRAL

STARTER ASSEMBLY
37-825066 DECAL-WARNING-HI VOLTAGE
37-825064 DECAL-CAUTION-START IN GEAR

CYLINDER BLOCK ASSEMBLY
34 37-819526  DECAL-THROTTLE CABLE ADJUSTMENT

SWIVEL BRACKET
NS 37-830253 DECAL-TILT LOCK (MANUAL TILT MODELS)


LITERATURE & PAINT
- 92-818252-12 AR PAINT-GRAPHITE GRAY ACRYLIC-12 OZ. (355 ML)-SPRAY CAN (CASE OF 12)
- 92-825321-12 AR PAINT-GRAPHITE GRAY ACRYLIC-.5 OZ. (15ML)-BRUSH BOTTLE (BOX OF 12)
- 92-819107-12 AR PAINT-CLEAR ACRYLIC-12 OZ. (355 ML)-SPRAY CAN (CASE OF 12) (FOR COWL ONLY)


37-820734A95 DECAL SET . . . . . . . . . . . 3 11
37-820735A95 DECAL SET . . . . . . . . . . . 3 11
37-809858A96 DECAL SET . . . . . . . . . . . 3 NS
37-809859A96 DECAL SET . . . . . . . . . . . 3 NS
37-835012A96 DECAL SET . . . . . . . . . . . 3 NS
37-852950A97 DECAL SET . . . . . . . . . . . 3 NS
37-852951A97 DECAL SET . . . . . . . . . . . 3 NS

37-817792A1 DECAL-TIMING . . . . . . . . . . 31 3
37-818029 DECAL-FUEL MIX . . . . . . . . . . 5 27
37-819526 DECAL-THROTTLE CABLE ADJUSTMENT . 25 34

37-825064 DECAL-CAUTION-START IN GEAR . . . 13 NS
37-825066 DECAL-WARNING-HI VOLTAGE . . . . . 13 NS
37-830253 DECAL-TILT LOCK . . . . . . . . . .37 NS





Serial Number: 0E195065 - Model: H050412SD - Model Version: ELPT
1996 FORCE FORCE 50 ELPT

MARINER 2B - Cat.# 90-92585

Cat.# 90-92585 MARINER 2B

TOP COWL DIAGRAM 38042

9336M TOP COWL ASSEMBLY PORT [M-076692] & Up
9206M TOP COWL ASSEMBLY PORT [M-061112] THRU [M-076691]
7869M TOP COWL ASSEMBLY PORT [M-061111] & Below

9337M TOP COWL ASSEMBLY STARBOARD [M-061112] & Up
7868M TOP COWL ASSEMBLY STARBOARD [M-061111] & Below



MARINER DECALS

810931A90 DECAL SIDE SET [M-142377] & Up

11906M DECAL SIDE SET [M-142376] & Below

Serial Number: 6A1 052480 - Model: 2B

13.5/15/15 BODENSEE (4-STROKE)

 > Mercury Marine [Updated: Apr. 12, 2023] > Outboard > 4 Stroke > 15 HP Carb 2 CYL > [1B227000 THRU 1B727495] - USA - Cat.# 90-803183006
Cat.# 90-803183006 13.5/15/15 BODENSEE (4-STROKE)

TOP COWL DIAGRAM 4698

852413T3 TOP COWL ASSEMBLY (BLACK)

852413T4 TOP COWL ASSEMBLY (SILVER)



MERCURY DECALS

802739A06 DECAL SET (15 MERCURY)

881842A06 DECAL SET (13.5 MERCURY)



MARINER DECALS

802740A06 DECAL SET (15 MARINER)

881843A06 DECAL SET (13.5 MARINER)



OTHER DECALS

804652A06 DECAL EPA Label Information (2006)
804652A07 DECAL EPA Label Information (2007)

Serial Number: 1B468544 - Model: 1F15203FD - Model Version: M 4 - 2006 MERCURY 4 STROKE 15 M 4

Serial Number: 1B468544
APR 2007
15M 4STR
Max RPM 5500
HP 15 KW 11
LB 112 KG 50.9
Mercury Marine
Brunswick Corp.
Fond du Lac, WI 54935
Assembled in the USA
from US and foreign
components
 [07]
Serial Number: 1B313198 - Model: 1F15301FD - Model Version: EH 4
2006 MERCURY 4 STROKE 15 EH 4

More Articles …

  1. 115/135/150 DFI (2.5L) - 2000 - Cat.# 90-80350200
  2. 150/200 EFI PROMAX/SUPERMAGNUM - Cat.# 90-80856798
  3. 200/225/250/200 PRO XS (3.0L)(MECHANICAL) - Cat.# 90-803485008
  4. 40/50 H.P. JET 30 (3 CYL.) - Cat.# 90-85207097

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips

    1. Ensure that the surrounding work area and the surface are properly cleaned to avoid contamination.

    90-8M0143239 eng MARCH 2018       © 2018 Mercury Marine      -     Page 1 / 16
