175 3.4L V6 PRO XS (4-STROKE)- [2B529482 & Up] - USA - Cat.# 90-8M0142638

> Mercury Marine [Updated: Dec. 13, 2023] > Outboard > 4 Stroke > 175 HP 3.4L V6 Pro XS > [2B529482 & Up] - USA - Cat.# 90-8M0142638


Top Cowl Diagram 68740

1  8M0142179 TOP COWL ASSEMBLY Pro XS, Decaled without Horsepower
+ 8M0182322 COWL TOP PROXS

FIT OTHER COVERS:

8M0142178 TOP COWL ASSEMBLY Black
8M0142180 TOP COWL ASSEMBLY Cold Fusion
8M0142181 TOP COWL ASSEMBLY Warm Fusion
8M0142182 TOP COWL ASSEMBLY Pearl Fusion
8M0142183 TOP COWL ASSEMBLY Sea Pro

8M0142179, 8M0182322, 8M0142178, 8M0142180, 8M0142181, 8M0142182, 8M0142183
8M0142179 8M0182322 8M0142178 8M0142180 8M0142181 8M0142182 8M0142183

11) 8M0142233 DOOR ASSEMBLY Black
15) 8M0148533 DECAL Latch Position



Lower Cowl

Lower Cowl Diagram 66952

1)    8M0142219 LOWER COWL ASSEMBLY Port and Starboard
41) 8M0142577 DECAL Read Manual, Clear
41) 8M0142371 DECAL Read Manual, Black
-    8M0142187 DECAL SET Pro XS Lower Chaps

MERCURY DECALS

Decals diagram 66976

1) 8M0142188 DECAL SET Pro XS Top Cowl
    2) 8M0214839 DECAL Fourstroke - Front Decal
    3) 8M0153042 DECAL Mercury, Silver - Rear Top MERCURY (13,16)
    4) 8M0214840 DECAL M-Icon, Red Service Door (18)

5) 8M0214849 DECAL SET Pro XS
    6) 8M0085373 DECAL M-Icon, 60mm Red - Front Logo (20)
    7) 8M0142371 DECAL Read Manual, Black - Front label

8) 8M0142198 DECAL SET 175 HP - Rear and Side carbon Numbers
    9) 8M0217482 DECAL 175 PXS Rear Numbers (12, 17)

10) 8M0214851 DECAL 175 HP Side Required for Top Cowl Replacement - Sides carbon Numbers

11) 8M0145995 DECAL 175 HP - Rear MERCURY - 175 - Pro
     12) 8M0217482 DECAL 175 PXS - Rear Numbers (9, 17)
     13) 8M0153042 DECAL Mercury, Silver - Rear Top MERCURY (3,16)

14) 8M0214850 DECAL 175 HP Required for Top Cowl Replacement
     15) 8M0159717 DECAL M Icon, 53 MM Red - Rear Bottom Logo
     16) 8M0153042 DECAL Mercury, Silver - Rear Top MERCURY (3, 13)
     17) 8M0217482 DECAL 175 PXS - Rear Numbers (9, 12)
     18) 8M0214840 DECAL M-Icon, Red Service Door (4)
     19) 8M0214841 DECAL V6 - Rear Emblem for new models - was not included on the first models
     20) 8M0085373 DECAL M-Icon, 60mm Red - Front Logo (6)

21) 8M0142187 DECAL SET Pro XS Lower Cowl - Chap stripes only

22) 8M0187221 DECAL 3D Circles, Black
23) 8M0187223 DECAL 3D Circles, White



Installation instructions V8 Accent panels

REDLINE RED V6: 8M0142211
PACIFIC BLUE V6: 8M0142212
MERCURY SILVERV6: 8M0142213
GRAPHITE GREYV6: 8M0142214
PRO BLACK (MATTE) V6: 8M0142215
READY-FOR-PAINT V6: 8M0142216

> Mercury Marine [Updated: Sep. 15, 2022] > Outboard > 4 Stroke > 175 HP 3.4L V6 Pro XS > [2B529482 & Up] - USA - Cat.# 90-8M0142638
> Mercury Marine [Updated: Feb. 18, 2019] > Outboard > 4 Stroke > 175 3.4L V6 PRO XS (4-STROKE) > [2B529482 & Up] - USA - Cat.# 90-8M0142638



Old Version

Decals diagram 66976 - old version

1) 8M0142188 DECAL SET Pro XS Top Cowl
2) 8M0145995 DECAL 175 HP
3) 8M0153042 DECAL Mercury, Silver
4) 8M0142198 DECAL SET 175 HP
5) 8M0043707 DECAL M-Icon, 53mm Red Front
6) 8M0085373 DECAL M-Icon, 60mm Red Rear
7) 8M0142187 DECAL SET Pro XS Lower Cowl

8) 8M0187221 DECAL 3D Circles, Black
9) 8M0187223 DECAL 3D Circles, White

Serial Number: 3B143966 - Model: 11750002A - Model Version: XL PROXS
MERCURY 175XL PXS 4.8" 1.85 175EFI XL PROXS

300 (3.0 L EFI ) Super Magnum - ProMax - Cat.# 90-85552998

> Mercury Marine [Updated: Oct. 31, 2019] > Outboard > 2 Stroke EFI > 300 (3.0L EFI) SuperMagnum > [0G610221 THRU 0T105297] - USA - Cat.# 90-85552998 > Service/Support Material
> Mercury Marine [Updated: Oct. 31, 2019] > Outboard > 2 Stroke EFI > 300 (3.0L EFI) ProMax > [0G610221 THRU 0T105297] - USA - Cat.# 90-85552998

Top Cowl (S/N-0G856999 and Below) DIAGRAM 34972



848792T2 TOP COWL ASSEMBLY (BLACK)

848792A4 TOP COWL ASSEMBLY (SILVER)
+ 848792T4 COWL TOP GRAY



MERCURY DECALS

849049A1 DECAL SET (BLACK)



MARINER DECALS

849065A1 DECAL SET (GRAY)



Top Cowl (S/N-0G857000 and Up) DIAGRAM 5089

848792T7 TOP COWL ASSEMBLY [0G980650] & Up
848792T5 TOP COWL ASSEMBLY (Black) [0G857000] THRU [0G980649]
848792T6 TOP COWL ASSEMBLY (Silver) [0G857000] THRU [0G980649]



848792T7, 848792T5, 848792T6,
848792T2,848792A4,848792T4

848792T7 848792T5 848792T6
848792T2 848792A4 848792T4



MERCURY DECALS

849049A1 DECAL SET (Black) [0G857000] THRU [0G980649]



MARINER DECALS

849065A1 DECAL SET (Silver) [0G857000] THRU [0G980649]
840323A16 DECAL SET Does not include 300 number decal [0G980650] & Up
840323A20 DECAL SET Complete Set - Includes 300 number decal [0G980650] & Up

1998 Mercury Race Outboard 3.0L [L MAGNUM] - 7930310GH Top Cowl(S/N-0G856999 and Below) section
1999 Mercury Race Outboard 300 [PROMAX] - 1930319VH Top Cowl(S/N-0G857000 and Up) section

30/40 CARB 4-STROKE (3 CYLINDER) - Cat.# 90-803941

 > Mercury Marine [Updated: Dec. 17, 2019] > Outboard > 4 Stroke > 40 (4-STROKE) > [0G760300 THRU 0T408999] - USA - Cat.# 90-803941
 > Mercury Marine [Updated: Dec. 17, 2019] > Outboard > 4 Stroke > 30 (4-STROKE) > [0G760300 THRU 0T408999] - USA - Cat.# 90-803941

TOP COWL DIAGRAM 9147


834785T5 TOP COWL ASSEMBLY (MANUAL - BLACK)
+ 834785T17 TOP COWL ASSEMBLY (MANUAL - BLACK)

834785T6 TOP COWL ASSEMBLY (MANUAL - SILVER)

834785T7 TOP COWL ASSEMBLY (ELECTRIC - BLACK)
+ 834785T22 TOP COWL ASSEMBLY (ELECTRIC - BLACK)

834785T8 TOP COWL ASSEMBLY (ELECTRIC - SILVER)

834785T17, 834785T5, 834785T6, 834785T22, 834785T7, 834785T8
834785T17 834785T5 834785T6 834785T22 834785T7 834785T8



MERCURY DECALS

803640A00 DECAL SET (BLACK 30)(1999 MODEL YEAR AND ABOVE)
+ 803640A99 DECAL SET (BLACK 30)

803644A99 DECAL SET (BLACK 40 BIGFOOT)(1999 MODEL YEAR)
+ 803644A00 DECAL SET (BLACK 40 BIGFOOT)(2000 MODEL YEAR AND ABOVE)
+ + 8M0099557 DECAL SET-MERCURY

803641A99 DECAL SET (BLACK 40)(1999 MODEL YEAR)
+ 803641A00 DECAL SET (BLACK 40)(2000 MODEL YEAR AND ABOVE)





MARINER DECALS

803642A99 DECAL SET (GRAY 30)(1999/2000 MODEL YEARS)
+ 803642A03 DECAL SET

803643A99 DECAL SET (GRAY 40)(1999/2000 MODEL YEARS)
+ 803643A03 DECAL SET

803645A99 DECAL SET (GRAY 40 BIGFOOT)(1999/2000 MODEL YEARS)
+ 803645A01 DECAL SET (GRAY 40 BIGFOOT)(2001 MODEL YEAR)

803642A01 DECAL SET (GRAY 30)(2001 MODEL YEAR)
+ 803642A03 DECAL SET

803643A01 DECAL SET (GRAY 40)(2001 MODEL YEAR)
+ 803643A03 DECAL SET

803645A01 DECAL SET (GRAY 40 BIGFOOT)(2001 MODEL YEAR)



TRACKER DECALS

803946A99 DECAL SET (TRACKER 30)
803947A99 DECAL SET (TRACKER 40)



OTHER DECALS

856985A22 DECAL EPA Label Information (1999)
804654A00 DECAL EPA Label Information (2000)
804654A01 DECAL EPA Label Information (2001)

Serial Number: 0G961010 - Model: 7F4S412JF - Model Version: ELPT 4
2000 MARINER 4 STROKE 50H/P DETUNED ITALY 40 ELPT 4

(4-STROKE)(232 cc) - 9.9 /8(BONDENSEE) 4 STROKE

Cat.# 90-80913195 9.9 (4-STROKE)(232 cc)

TOP COWL DIAGRAM 37381

1

854654A3 TOP COWL ASSEMBLY (BLACK) [0H013400] & Up

854654A4 TOP COWL ASSEMBLY (SILVER) [0H013400] & Up

825553A4 TOP COWL ASSEMBLY (BLACK) [0H013399] & Below

825553A5 TOP COWL ASSEMBLY (SILVER) [0H013399] & Below

852413T3 TOP COWL ASSEMBLY (Black)

852413T4 TOP COWL ASSEMBLY (Silver)

MERCURY DECALS

8302584 DECAL (BLACK/TRACKER)[0H013399] & Below (4 STROKE)

8500534 DECAL (BLACK/TRACKER)[0H013399] & Up (4 STROKE)

826335A96 DECAL SET (BLACK 9.9) [0H013399] & Below

809727A96 DECAL SET (BLACK 8 BODENSEE)[0H013399] & Below

826335A98 DECAL SET (BLACK 9.9) [0H013400] & Below

809727A98 DECAL SET (BLACK 8 BODENSEE) [0H013400] & Below



MARINER DECALS

8500534 DECAL (GRAY) [0H013400] & Up (FOUR STROKE)

8263367 DECAL (GRAY) [0H013400] & Below (FOUR STROKE)

826336A95 DECAL SET (GRAY 9.9) [0H009514] & Below

809710A96 DECAL SET (GRAY 8 BODENSEE) [0H009514] & Below

826336A97 DECAL SET (GRAY 9.9) [0H009515] THRU [0H013399]

809710A97 DECAL SET (GRAY 8 BODENSEE)[0H009515] THRU[0H013399]

826336A98 DECAL SET (GRAY 9.9) [0H013400] & Up

809710A98 DECAL SET (GRAY 8 BODENSEE) [0H013400] & Up



TRACKER DECALS

853556A97 DECAL SET (9.9 TRACKER)



OTHER DECALS

85557723 DECAL EPA Label Information (1998)

1998 MERCURY 9.9 EL 4S

Serial Number: 0H016381 - Model: 1F10312UD - Model Version: ELRC 4
1998 & Newer MERCURY 4 STROKE 9.9 ELRC 4
Cat.# 90-80913195 9.9 (4-STROKE)(232 cc) 0H00058 THRU OH016909 - USA

Serial Number
0H016381
1998
9.9EL 4ST
5500 max rpm
LB 9.9 KG 7.4
LB 103 KG 47MERCURY MARINE
BRUNSWICK CORP.
FOND DU LAC, WI 54935
MADE IN USA
CE [98]

More Articles …

  1. 200/225/250/275 4-STROKE VERADO
  2. 1982 Outboard | Chrysler 30 HP - ARCHIVE CAT FOB3776
  3. 75/80/90/100 EFI 4-STROKE - Cat.# 90-898112006
  4. 55/60 JET 40 (3 CYLINDER) - Cat.# 90-803022001

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips

    1. Ensure that the surrounding work area and the surface are properly cleaned to avoid contamination.

    90-8M0143239 eng MARCH 2018       © 2018 Mercury Marine      -     Page 1 / 16
