> Mercury Marine [Updated: Sep. 4, 2025]  > Outboard > 4 Stroke EFI > 15 HP  EFI 2 CYL > [0R833820 & Up] - Cat.# 90-8M0125267
> Mercury Marine [Updated: Dec. 13, 2023] > Outboard > 4 Stroke > 15 HP  EFI 2 CYL > [0R833820 & Up] - Cat.# 90-8M0125267
> Mercury Marine [Updated: Sep. 15, 2022] > Outboard > 4 Stroke > 9.9 HP EFI 2 CYL > [1R008146 THRU 1R162636] - Cat.# 90-8M0125267
> Mercury Marine [Updated: Oct. 8, 2021]  > Outboard > 4 Stroke > 9.9 HP EFI 2 CYL > [1R008146 & Up] - Cat.# 90-8M0125267
> Mercury Marine [Updated: Feb. 25, 2019] > Outboard > 4 Stroke > 15 EFI (2CYL)(4-STROKE) > [0R833820 & Up] - Cat.# 90-8M0125267 >

Decals Top Cowl

Top Cowl Diagram 65113

1 8M0134515 TOP COWL ASSEMBLY Black, Non Decaled
1 8M0134516 TOP COWL ASSEMBLY Silver, Non Decaled

8M0134515, 8M0134516
8M0134515 8M0134516

Decals Top Cowl

MERCURY DECALS

Decals Top Cowl - Serial #0R991812 and Below
Diagram 65115

1 8M0132330 DECAL SET Mercury
2 8M0132331 DECAL SET SeaPro
3 8M0082467 DECAL Horsepower 10 Non-SeaPro
4 8M0073690 DECAL Horsepower 15
5 8M0073691 DECAL Horsepower 20 Non-SeaPro
6 8M0050645 DECAL M-icon
7 8M0056643 DECAL Read Manual

9  8M0132332 DECAL SET ProKicker
10 8M0076191 DECAL NOTICE THIS SIDE UP
+ https://garzonstudio.com/catalogsearch/result/?q=8M0157275 DECAL Notice This Side Up
11 859278004 DECAL Start
12 896854007 DECAL Oil Pressure

13 https://garzonstudio.com/catalogsearch/result/?q=8M0043700 M-ICON Red, 39mm

MARINER DECALS

8 8M0132333 DECAL SET Mariner

Decals Top Cowl - Serial #0R991813 and Above
DIAGRAM 71257

1 8M0170757 DECAL SET 10, 15, 20 HP
2 8M0082467 DECAL Horsepower 10 Non-SeaPro
3 8M0073690 DECAL Horsepower 15
4 8M0073691 DECAL Horsepower 20 Non-SeaPro
5 8M0050645 DECAL M-icon
6 8M0056643 DECAL Read Manual
7 8M0161263 DECAL Rear 9.9 HP Non-SeaPro

8 8M0132331 DECAL SET SeaPro
8M0180066 DECAL Maintenance, Blue - SeaPro

9 8M0132333 DECAL SET Mariner

10 8M0132332 DECAL SET ProKicker
11 8M0173449 DECAL Rear, 9.9 HP ProKicker
12 8M0173831 DECAL Rear, 15 HP Prokicker
13 8M0043700 M-ICON Red, 39mm
17 8M0180068 DECAL Maintenance, 9.9 ProKicker

14 8M0076191 DECAL NOTICE THIS SIDE UP
    + 8M0157275 DECAL Notice This Side Up

15 859278004 DECAL Start
16 896854007 DECAL Oil Pressure

Read more: 2021-2022 10/15/20 HP EFI (2CYL)(4-STROKE) - Cat.# 90-8M0125267

> Mercury Marine [Updated: Dec. 13, 2023] > Outboard > 4 Stroke > 175 HP 3.4L V6 Pro XS > [2B529482 & Up] - USA - Cat.# 90-8M0142638

Top Cowl Diagram 68740

1  8M0142179 TOP COWL ASSEMBLY Pro XS, Decaled without Horsepower
+ 8M0182322 COWL TOP PROXS

FIT OTHER COVERS:

8M0142178 TOP COWL ASSEMBLY Black
8M0142180 TOP COWL ASSEMBLY Cold Fusion
8M0142181 TOP COWL ASSEMBLY Warm Fusion
8M0142182 TOP COWL ASSEMBLY Pearl Fusion
8M0142183 TOP COWL ASSEMBLY Sea Pro

8M0142179, 8M0182322, 8M0142178, 8M0142180, 8M0142181, 8M0142182, 8M0142183
8M0142179 8M0182322 8M0142178 8M0142180 8M0142181 8M0142182 8M0142183

11) 8M0142233 DOOR ASSEMBLY Black
15) 8M0148533 DECAL Latch Position

Lower Cowl

Lower Cowl Diagram 66952

1)    8M0142219 LOWER COWL ASSEMBLY Port and Starboard
41) 8M0142577 DECAL Read Manual, Clear
41) 8M0142371 DECAL Read Manual, Black
-    8M0142187 DECAL SET Pro XS Lower Chaps

MERCURY DECALS

Decals diagram 66976

1) 8M0142188 DECAL SET Pro XS Top Cowl
    2) 8M0214839 DECAL Fourstroke - Front Decal
    3) 8M0153042 DECAL Mercury, Silver - Rear Top MERCURY (13,16)
    4) 8M0214840 DECAL M-Icon, Red Service Door (18)

5) 8M0214849 DECAL SET Pro XS
    6) 8M0085373 DECAL M-Icon, 60mm Red - Front Logo (20)
    7) 8M0142371 DECAL Read Manual, Black - Front label

8) 8M0142198 DECAL SET 175 HP - Rear and Side carbon Numbers
    9) 8M0217482 DECAL 175 PXS Rear Numbers (12, 17)

10) 8M0214851 DECAL 175 HP Side Required for Top Cowl Replacement - Sides carbon Numbers

11) 8M0145995 DECAL 175 HP - Rear MERCURY - 175 - Pro
     12) 8M0217482 DECAL 175 PXS - Rear Numbers (9, 17)
     13) 8M0153042 DECAL Mercury, Silver - Rear Top MERCURY (3,16)

14) 8M0214850 DECAL 175 HP Required for Top Cowl Replacement
     15) 8M0159717 DECAL M Icon, 53 MM Red - Rear Bottom Logo
     16) 8M0153042 DECAL Mercury, Silver - Rear Top MERCURY (3, 13)
     17) 8M0217482 DECAL 175 PXS - Rear Numbers (9, 12)
     18) 8M0214840 DECAL M-Icon, Red Service Door (4)
     19) 8M0214841 DECAL V6 - Rear Emblem for new models - was not included on the first models
     20) 8M0085373 DECAL M-Icon, 60mm Red - Front Logo (6)

21) 8M0142187 DECAL SET Pro XS Lower Cowl - Chap stripes only

22) 8M0187221 DECAL 3D Circles, Black
23) 8M0187223 DECAL 3D Circles, White

Installation instructions V8 Accent panels

REDLINE RED V6: 8M0142211
PACIFIC BLUE V6: 8M0142212
MERCURY SILVERV6: 8M0142213
GRAPHITE GREYV6: 8M0142214
PRO BLACK (MATTE) V6: 8M0142215
READY-FOR-PAINT V6: 8M0142216

> Mercury Marine [Updated: Sep. 15, 2022] > Outboard > 4 Stroke > 175 HP 3.4L V6 Pro XS > [2B529482 & Up] - USA - Cat.# 90-8M0142638
> Mercury Marine [Updated: Feb. 18, 2019] > Outboard > 4 Stroke > 175 3.4L V6 PRO XS (4-STROKE) > [2B529482 & Up] - USA - Cat.# 90-8M0142638

Old Version

Decals diagram 66976 - old version

1) 8M0142188 DECAL SET Pro XS Top Cowl
2) 8M0145995 DECAL 175 HP
3) 8M0153042 DECAL Mercury, Silver
4) 8M0142198 DECAL SET 175 HP
5) 8M0043707 DECAL M-Icon, 53mm Red Front
6) 8M0085373 DECAL M-Icon, 60mm Red Rear
7) 8M0142187 DECAL SET Pro XS Lower Cowl

8) 8M0187221 DECAL 3D Circles, Black
9) 8M0187223 DECAL 3D Circles, White

Serial Number: 3B143966 - Model: 11750002A - Model Version: XL PROXS
MERCURY 175XL PXS 4.8" 1.85 175EFI XL PROXS

> Mercury Marine [Updated: Feb. 16, 2019] > Outboard > 2 Stroke Carb > 3.5 > ARCHIVE CAT 822366

PARTS CATALOG
3.5 H.P.
SERIAL NUMBER
3.5 . . . . . . . . . 642-23740 AND BELOW
3.5 . . . . . . . . . 642-41690 AND BELOW
90-822366 © Mercury Marine 2003 ---- 02-01-2002

COWLING

Diagram 2 P3

1 STARBOARD COWL
2 2168-7158M PORT COWL
8 80283M COVER

2168-7158M, 80283M
2168-7158M 80283M

MARINER DECALS

3 NLA8- TRIM DECAL (2 pieces)
4 37-80294M SHIFT DECAL
9 REAR DECAL

FUEL TANK

Diagram 18 P20

1 NLA 1 FUEL TANK
2 NLA 1 DECAL SET
3 NLA 1 REAR DECAL

> Mercury Marine [Updated: Dec. 20, 2018] > Outboard > 2 Stroke Carb > 5C > ARCHIVE CAT 96387

5 H.P. SERIAL NUMBER
5C . . . . . M 6E3-102151 AND UP
5C . . . . . ML 6E3-400101 AND UP

COWLING DIAGRAM 96387-6-P4

1
2168-811007M TOP COWLING ASS’Y SERIAL (M-162953 ML-435351) AND ABOVE
2168-9657M TOP COWLING ASS’Y SERIAL (M-162952 ML-435350) AND BELOW

MARINER DECALS

2
37-810933A90 DECAL, SIDE SET SERIAL (M-162953 ML-435351) AND ABOVE
37-11924M DECAL, SIDE SET SERIAL (M-136244 THRU 162952 ML-420839 THRU 435350)
37-98964M DECAL, SIDE SET SERIAL (M-136243 ML-420838) AND BELOW

3
NSS DECAL, FRONT (PART OF 37-810933A90) SERIAL (M-162953 ML-435351) AND ABOVE
37-11914M DECAL, FRONT SERIAL (M-162952 ML-435350) AND BELOW

OTHER DECALS

8 37-81202M DECAL, SHIFT

FUEL TANK AND FUEL LINE ASSEMBLY DIAGRAM 96387-46-P44

1
37-95539M DECAL, SIDE (ENGLISH)
37-95540M DECAL, SIDE (FRENCH)

2
37-95489M DECAL, TOP (ENGLISH)
37-95503M DECAL, TOP (FRENCH)

FUEL TANK AND FUEL LINE ASSEMBLY DIAGRAM 96387-48-P46

1
37-95488M DECAL, SIDE (MARINER) SERIAL (M-006976 THRU 129815 ML-304984 THRU 418072)
37-83057M DECAL, SIDE (MARINER) SERIAL (M-006975 ML-304983) AND BELOW

2
37-95489M DECAL, SIDE (CAUTION) SERIAL (M-006976 THRU 129815 ML-304984 THRU 418072)
37-83765M DECAL, SIDE (CAUTION) SERIAL (M-006975 ML-304983) AND BELOW

FUEL TANK AND FUEL LINE ASSEMBLY DIAGRAM 96387-50-P48

1) 1259-812410A1 FUEL TANK, COMPLETE
2) 37-13921 DECAL, FUEL TANK
3) 36-14223M FILLER CAP ASSEMBLY
